ACR Heat Shield for Wychwood Model
ACR Heat Shield for Wychwood Model
Couldn't load pickup availability
With over 30 years of experience in manufacturing woodburning, multifuel, and electric stoves, ACR has combined cutting-edge technology with stylish design to create the stunning Wychwood wood burning stove.
The ACR Wychwood is EcoDesign Ready and DEFRA Approved, meaning it is fully approved for wood burning in smoke-controlled areas.
With its contemporary styling and large landscape glass window, the Wychwood creates a beautiful focal point while offering an exceptional view of the flames.
Specifications:
Key Features
-
DEFRA Approved – Suitable for use in smoke control zones.
-
EcoDesign 2022 Compliant – Burns cleanly and efficiently with reduced emissions.
-
Contemporary Design – Clean lines and large glass door for a modern look.
-
Matt Black Finish – Durable and elegant.
-
5 kW Nominal Output – Ideal for small to medium-sized rooms.
-
High Efficiency – 75.1% gross / 82.2% net efficiency.
-
Very Powerful Airwash System – Keeps the glass panel clear for a better flame view.
-
Dedicated Wood Burner – Optimized for burning logs.
-
Large Viewing Window – Provides a relaxing, unobstructed view of the fire.
-
Optional Pewter Handle Available – Customizable style to suit your décor.
-
Optional Direct Air Supply Kit – 80 mm spigot for external air connection.
-
Optional Rear Heat Shield – Allows installation just 100 mm from combustible materials at the rear, and 250 mm at the sides (must use insulated flue pipe to enclose the flue collar).
-
12 mm Hearth Compatible – Can be installed on a superficial hearth.
-
High-Quality Steel Construction – For efficient heat transfer and long-lasting performance.
-
Warranty: 10-year manufacturer-backed warranty (on casting).
Technical Specifications
-
Model Name: ACR Wychwood
-
Fuel Type: Wood
-
Nominal Heat Output: 5 kW
-
Heat Output Range: 3 kW – 6.5 kW
-
Net Efficiency: 82.2%
-
Gross Efficiency: 75.1%
-
Maximum Hearth Temperature: Less than 100°C
-
Weight: 90 kg
-
Maximum Log Length: 35 cm
-
Flue Diameter: 125 mm (internal)
-
Flue Location: Top or Rear
-
Distance from Floor to Centre of Rear Flue Outlet: 422 mm
-
Distance from Rear to Centre of Top Flue Outlet: 127 mm (may increase if optional heat shield is installed)
-
Construction Material: Steel
-
Warranty: 10-year manufacturer-backed (on casting)
Share
- Description
- Specifications:
- Delivery & Returns
With over 30 years of experience in manufacturing woodburning, multifuel, and electric stoves, ACR has combined cutting-edge technology with stylish design to create the stunning Wychwood wood burning stove.
The ACR Wychwood is EcoDesign Ready and DEFRA Approved, meaning it is fully approved for wood burning in smoke-controlled areas.
With its contemporary styling and large landscape glass window, the Wychwood creates a beautiful focal point while offering an exceptional view of the flames.
Key Features
-
DEFRA Approved – Suitable for use in smoke control zones.
-
EcoDesign 2022 Compliant – Burns cleanly and efficiently with reduced emissions.
-
Contemporary Design – Clean lines and large glass door for a modern look.
-
Matt Black Finish – Durable and elegant.
-
5 kW Nominal Output – Ideal for small to medium-sized rooms.
-
High Efficiency – 75.1% gross / 82.2% net efficiency.
-
Very Powerful Airwash System – Keeps the glass panel clear for a better flame view.
-
Dedicated Wood Burner – Optimized for burning logs.
-
Large Viewing Window – Provides a relaxing, unobstructed view of the fire.
-
Optional Pewter Handle Available – Customizable style to suit your décor.
-
Optional Direct Air Supply Kit – 80 mm spigot for external air connection.
-
Optional Rear Heat Shield – Allows installation just 100 mm from combustible materials at the rear, and 250 mm at the sides (must use insulated flue pipe to enclose the flue collar).
-
12 mm Hearth Compatible – Can be installed on a superficial hearth.
-
High-Quality Steel Construction – For efficient heat transfer and long-lasting performance.
-
Warranty: 10-year manufacturer-backed warranty (on casting).
Technical Specifications
-
Model Name: ACR Wychwood
-
Fuel Type: Wood
-
Nominal Heat Output: 5 kW
-
Heat Output Range: 3 kW – 6.5 kW
-
Net Efficiency: 82.2%
-
Gross Efficiency: 75.1%
-
Maximum Hearth Temperature: Less than 100°C
-
Weight: 90 kg
-
Maximum Log Length: 35 cm
-
Flue Diameter: 125 mm (internal)
-
Flue Location: Top or Rear
-
Distance from Floor to Centre of Rear Flue Outlet: 422 mm
-
Distance from Rear to Centre of Top Flue Outlet: 127 mm (may increase if optional heat shield is installed)
-
Construction Material: Steel
-
Warranty: 10-year manufacturer-backed (on casting)
